The Occluform-3 is an occludator that can be integrated in a thermoforming unit to imprint the opposing bite (pat. 19915567) and can only be installed at the Erkoform units serie 3.The construction of the Occluform-3 unit is based on a Bonwill triangle with side length of 11.5 cm and a Balkwill angle of 20°.


The construction dimensions of the Occluform-3 allow a bite elevation at average values. The elevation of 1 line at the supporting pin corresponds to approx. 1 mm bite elevation at the incisal point.
If a construction bite is at disposal the models are articulated in the Occluform-3 using this construction bite.

Delivery Contents

Occluform-3, occludating bow with fixation ring for Erkoform units serie 3, model pot for fixation of the model in the unit form pot, Occ3-aM with model pot support, granules shovel, hexagonal socket wrench size 3


The Occluform-3 allows to directly imprint the opposing bite in the Erkoform units serie 3 during the thermoforming process.
